Introduction
Version	OA V5.0.40.3.086
Cooling Method	Oil Cooling
Miner Capacity	144 units(Avalon Miner)
Container Certification	Classification Society
Safety Certification*	IEC
Input Voltage and Frequency	380V~415V, AC, 50Hz (A, B, C, N, PE)
Basic Capacity
Power Capacity for Miners	1200 kW@25℃(Avalon Miner)
Maximum Power@Single Position	6.0 kW
PUE	≤1.08
Basic Configuration
Critical Equipment	Configuration or Dimensions
Tank Container	LxWxH：12192x2438x2896 mm
Cooling Container**	LxWxH：12192x2438x2896 mm
Tank	18 units@single Tank
Power Distribution Cabinet**	1250A x 2 sets
PDU**	250A，30A x 18 sets
Switch	Aggregation and  terminal switches
Coolant Pump	Customized pumps
Cooling Unit**	1000kW@25℃
Control System**	PLC, monitoring, start-stop, alarming
Others	Integrated smoke sensor, temperature sensor, ventilator
Conditions of Carriage
Tank Container	Shipping Weight (T)≤15 Operating Weight (T)≤25
Cooling Container	Shipping Weight (T)≤12 Operating Weight (T)≤20
Noise
Sound Pressure LpA (10m)	≤70 dB(A)
Key materials
Dry Cooler**	Copper tube Aluminum fins
Pipe	SS304
Annotation
*UL, CSA need to be customized. **These can be adapted to customer requirement.
